One-component room temperature moisture curing RTV
Corning's one-component moisture-curing adhesives typically cure at room temperature and relative humidity of 30%-80%, and can cure physical properties to more than 90% of full performance within 24-72 hours, depending on the product selected. Items and parts can be completed in less time, approximately 10-120 minutes, depending on the product selected and the dosage used on each part. These items are not intended for high containment or deep curing, and items are typically cured 0.25 inches every 7 days from the exposed surface, depending on the humidity in the air. The operating time from product use to surface dry formation typically takes a few minutes to 1 hour, and slight warming may speed up curing, but it is recommended not to exceed 60°C (140°F).
two components condensed and cured at room temperature
Corning's two-component room temperature curing adhesives are mixed and cured quickly at room temperature to achieve good strength within 1 hour, but full performance is not achieved until a few days later. These adhesives contain their own humidity and cure evenly throughout the item, allowing for deep curing or containment, but there are some limitations.
heat curing
Corning additive curing adhesives should cure at temperatures of 100°C (212°F) or above, and cure quickly after warming。 For thicker sections or when bubbles are found, choose an adhesive with a newer one with fewer bubbles, or pre-cure at 70°C (158°F) for 30 minutes, which reduces bubbles in the elastomer. Additive curing contains all components of curing action, the curing process produces no by-products, can be cured deep or under closed coverage, the curing process is uniformly spread throughout the item, and these adhesives usually have a long working time.

单组分室温湿气固化
类别:
无腐蚀性,单或两组分室温湿气固化硅酮弹性体;在室温条件下固化而不需加热
外观:
不流动和可流动两种选择;固化成柔性弹性体
特性:
室温固化;不透明和半透明两种选择;可以抵御潮湿和其它恶劣的环境;良好的介电特性;对多种普通基材具有良好的粘合性;低应力,精炼型,可快速表干;两组分物品同样可以在室温条件下提供快速固化和初期强度,以及可以深层固化。
用途:
密封模块和外壳;垫圈;密封电子仪器设备及模块;固定电源供应器电路板零部件,安装CRT, LCD/LED/PDP模快、外壳、垫圈、连接电子零部件。
两组份室温缩合固化
类别:
两组分室温固化硅酮弹性体
外观:
不流动;固化成柔性弹性体
特性:
在室温下快速固化及取得初期强度;深层固化;可以抵御潮湿和其它恶劣的环境;良好的介电特性;自粘;低应力
用途:
盖子和外壳密封;垫圈
加热固化
类别:
提供多种应用和固化形式的单或两组分硅酮弹性体
外观:
不流动和可流动两种选择;固化成柔性弹性体;有多种固化形式和特性
特性:
较低温快速热固化;可以抵御潮湿和其它恶劣的环境;良好的介电特性;自粘;低应力,固化过程中较少出现气泡
用途:
盖子和外壳密封;发动机控制模块密封、电源模块; 固定电路板的电子零部件;加固或固定连接器部件;密封电子部件/模块;密封电容器和电子组件;固定回扫变压器
| Corning products | > description | > features | > potential or typical use |
| One-component room temperature humidity curing | |||
| EA-3000 white | one-component, white, fast stem | fast stem; low viscosity; non-corrosive (alcohol curing at room temperature); Excellent adhesion to most materials; self-adhesive; Excellent dielectric properties; Excellent thermal stability and cold resistance; Refined | LCD & EL module assembly |
| SE 9120 Transparent | one-component, flowable; Translucent, room temperature moisture curing | Fast surface drying time; non-corrosive; Refined | EL, LCD module assembly; Mixing IC and PCB coatings, sealing electronic components |
| SE 9120 S white | one-component, flowable; white, room temperature moisture curing | fast surface drying time; non-corrosive; Refined type | EL, LCD module assembly |
| SE 9152 HT | one-component, flowable; Reddish-brown, room temperature moisture curing | fast surface drying time; non-corrosive; Heat-resistant temperature up to 275°C | sealed sheathed heating tube tail end |
| SE 9186 Transparent or white | one-component, flowable; Translucent or white, room temperature moisture curing | fast surface drying time; non-corrosive; Refined < | td class="et2" x:str="" align="left" valign="middle"> sealed electronic instruments and modules; Fixed circuit board parts|
| SE 9186 L Black or transparent | one-component, flowable; Black or translucent, room temperature moisture curing | Fast surface drying time; non-corrosive; Refined type | Circuit board parts repair; LCD module assembly |
| SE 9187 L Black or clear or white | One component, low viscosity, black, translucent or white, room temperature moisture curing | fast table drying time; non-corrosive; Refined, UL 94HB (black only) | LCD module assembly; LED module assembly; potting |
| 3140 room temperature curable coatings | one-component, medium flow; Translucent, room temperature moisture curing | non-corrosive; Good curing strength; Contains ultraviolet fluorescence markers for automatic detection; UL 94V-1 and MIL-A-46146 | seals in notches or other fluid-supporting object configurations, or where limited flow is required |
| SE 9189 L Grey or White Cured at room temperature | one-component, medium flowability; Grey or white, room temperature moisture curing | fast surface drying time; non-corrosive; Refined type; UL V-0 | PDP module assembly; Fixed circuit board parts |
| 3-1944 Room temperature curing coatings | one-component, medium flow; Translucent, room temperature moisture curing | Fast surface drying time; non-corrosive; Contains ultraviolet fluorescence markers; UL 94V-0 and MIL-A-46058 | seals in notches or other configurations that support flow, or where limited flow is required |
| SE 738 white | one-component, non-flowing; white, room temperature moisture curing | non-corrosive; General Purpose; UL 94HB | fixed circuit board capacitor coil |
| 739 Plastic Adhesive-White | non-corrosive; General Purpose; Good adhesion; UL 94V-0 | Contract Fixation or CRT; Fixed power supply mold fast parts | |
| 744 room temperature curing sealant | non-corrosive; Fast surface drying time; General Purpose; Good adhesion | fixing large components such as batteries or circuit board capacitors | |
| 838 Silicone Adhesives/Sealants | non-corrosive; General Purpose; UL 94HB | openings and housings of sealing modules; Increase mechanical stability for each component; Installing components on PWBs; sealing the inner and outer edges of cables and electronic conductors; Yoke installation | |
| 839 silicone adhesives/sealants | one-component, non-flowing; Translucent blue, room temperature moisture curing | non-corrosive; General use | openings and housings of sealing modules; Increase mechanical stability for each component; Installing components on PWBs; sealing the inner and outer edges of cables and electronic conductors; Yoke installation |
| 3145 Room temperature curing MIL-A-46146 Adhesives/sealants - clear | One component, Not mobile; Translucent, room temperature moisture curing | non-corrosive; high tensile strength, elongation and peel shear values; Contains ultraviolet fluorescence markers for automatic detection; MIL-A-46146 | Openings and housings of sealed modules; Increase mechanical stability for each component; Installing components on PWBs; sealing the inner and outer edges of cables and electronic conductors; Yoke installation |
| 3145 Room temperature curing MIL-A-46146 Adhesives/sealants-gray | one-component, Not mobile; Grey, room temperature moisture curing | non-corrosive; high tensile strength, elongation and peel shear values; for high-temperature applications; MIL-A-46146 | |
| 3165 Fast surface dry room temperature curing adhesive/sealant 1 | one-component, non-flowing; gray, room temperature moisture curing | fast surface drying time; non-corrosive; Good initial strength; Good room temperature adhesion to most substrates; UL 94V-0 | |
| SE 9168 Cured at room temperature | one-component, non-flowing; gray, room temperature moisture curing | fast surface drying time; non-corrosive; Refined type; UL 94V-0 | parts of the circuit board that fixes the CRT and power supply modules |
| SE 9184 White room temperature curing | one-component, non-flowing; white, room temperature moisture curing | fast surface drying time; non-corrosive; Refined type; Thermal conductivity; UL94V-0 | Parts of the circuit board that fix the power supply module; Heat conduction of electronic components |
| SE 9185 Transparent or white | one-component, non-flowing; Translucent or white, room temperature moisture curing | fast surface drying time; non-corrosive; Refined < | td class="et2" x:str="" align="left" valign="middle"> sealed electronic instruments and modules; fixed circuit board parts|
| SE 9188 Room temperature curing | one-component, non-flowing; gray, room temperature moisture curing | fast surface drying time; non-corrosive; Refined type; UL 94V-0 | Parts that fix CRT, power supply module circuit board |
| SE 9189 White cured at room temperature | one-component, non-flowing; white, room temperature moisture curing | fast surface drying time; non-corrosive; Refined type; UL 94V-0; Good thermal conductivity | parts of fixed power supply module circuit board |
| two components condensed and cured at room temperature | |||
| CY 51-019 | Two components, 10:1 mixing ratio, white, condensation curing at room temperature | non-corrosive; Good liquidity; Good adhesion | solar cell seal |
| Q3-6093 room temperature curing adhesive | Two components, 10:1 mixing ratio, black, room temperature condensation curing | non-corrosive; self-adhesive; Fast room temperature curing and deep curing; Good initial strength; Good room temperature adhesion to most substrates | seal lids and case cases; connecting substrates; washer |
| heat curing | |||
| Sylgard® 577 Primless Silicone Adhesive | Two components, 10:1 mixing ratio, flowable, gray, Heat curing | non-corrosive; Fast heating and curing; self-adhesive; High strength; UL 94V-0; MIL-PRF-23586F | sealing lids and enclosures; connecting substrates; Gaskets, contact seals |
| 866 Primless silicone adhesive | one-component, flowable, gray, heat curable | non-corrosive; self-adhesive; High Strength | sealing lids and housings; connecting substrates; Gaskets, contact seals |
| SE 1701 LTV1 | Two components, 10:1 mixing ratio, flowable, beige, heat cured | non-corrosive; self-adhesive; High Strength | sealed ceramic capacitors; sealing electronic components; Fixative for computer keyboards |
| SE 17131 | one-component, flowable, beige, heat cured | non-corrosive; self-adhesive; High strength; Good adhesion | sealing ECUs cover and housing, power module; fixed circuit board electronic components; Reinforced or fixed connector assembly |
| SE 1714 or SE 1714 black | one-component, flowable, beige or black, heat cured | ||
| SE 1720 CV1 | Two components, 1:1 mixing ratio, white, low bubble rate, fast curing, refined type | non-corrosive; self-adhesive; High strength; non-collapsing | |
| SE 1750 white1 | one-component, flowable, white, heat curable | non-corrosive; self-adhesive; Good strength; Good adhesion | sealing ECUs cover and housing, power module; fixed circuit board electronic components; Reinforced or fixed connector assembly |
| 3-1595 Silicone Adhesives | one-component, thixotropic, gray, heat cured | self-adhesive; Soft | seal lid and housing; Connecting the base plate; Washers; Connector sealing; engine control; ABS; Transmission Motor; lighting equipment |
| 3-1598 HP | one-component, low bubble rate, black, flowable | High performance product 3-1598, which can be used especially to reduce air bubbles in cured materials | |
| 3-6265 HP | one-component, low bubble rate, black, non-flowing | High performance product 3-6265, which can be used especially to reduce air bubbles in cured materials | |
| 3-6876 Black adhesive | One component, good flowability, black, heat cured | non-corrosive; self-adhesive; Fast heating and curing; High strength; Low viscosity product Q3-6611 adhesive | |
| 3-6876 Grey Adhesive | One-component, good flowability, gray, heat cured | ||
| 96-083 silicone adhesive | Two components, 10:1 mixing ratio, low viscosity, heat curing | non-corrosive; self-adhesive; heating curing; High strength; Low viscosity | fixed components; Fixing various substrates such as ceramics, plastics, glass and metals |
| EA-6052 Fast Low Temperature Curing Adhesive | Two components, 1:1 mixing ratio, medium flow, black, Heat curing | non-corrosive; Fast low-temperature curing; flowing to fill grooves; Sealed lid and housing with auto-detection UV fluorescence markers | ; connecting substrates; Gaskets, connector seals |
| X3-1598 adhesive | One-component black heat curing, medium flow, high strength, Similar products Q3-6611 adhesive contains UV markers, self-adhesive | non-corrosive; self-adhesive; Fast heating and curing; High strength; flowable; Contains UV fluorescence markers with automatic detection | sealing lid and housing; Connecting the base plate; Washers; Connector sealing; engine control; ABS; Transmission Motor; lighting equipment |
| Q3-6611 Adhesive, black | one-component, medium flow, black, heat cured | non-corrosive; self-adhesive; Fast heating and curing; High Strength | |
| Q3-6611 Adhesive, grey | one-component, medium flow, gray, heat cured | ||
| Q5-8401 Adhesive | Two components, 1:1 mixing ratio, medium flow, gray, heat curing | non-corrosive; self-adhesive; High strength; | |
| EA-6054 Thixotropic Fast Low Temperature Curing Adhesive | Two components, 1:1 mixing ratio, non-flowing, black, Heat curing | non-corrosive; Fast low-temperature curing; does not collapse; Sealed lid and housing with auto-detection UV fluorescence markers | ; Connecting the base plate; Washers; Multiplane point |
| SE 1700 Transparent 1 | Two components, 10:1 mixing ratio, non-flowing, translucent, heat cured | non-corrosive; self-adhesive; High Strength | sealed ceramic capacitors; sealing electronic components; Fixative for computer keyboards |
| SE 1700 white 1 | Two components, 10:1 mixing ratio, non-flowing, white, heat curing | non-corrosive; self-adhesive; High Strength | sealed ceramic capacitors; sealing electronic components; Fixative for computer keyboards |
| Q1-9225 Silicone Adhesive | Two components, 10:1 mixing ratio, non-collapsing, white, heat cured | self-adhesive; High Strength | sealed ceramic capacitors; sealing electronic components; Computer keyboard fixative |
| 3-6265 Thixotropic Adhesives | one-component, non-flowing, black, heat cured | non-corrosive; self-adhesive; Fast heating and curing; High strength; Non-flowing product Q3-6611 adhesive; Sealed lid and housing with auto-detection UV fluorescence markers | ; Connecting the base plate; Washers;Terminator seal |
