Adhesive


One-component room temperature moisture curing RTV

Corning's one-component moisture-curing adhesives typically cure at room temperature and relative humidity of 30%-80%, and can cure physical properties to more than 90% of full performance within 24-72 hours, depending on the product selected. Items and parts can be completed in less time, approximately 10-120 minutes, depending on the product selected and the dosage used on each part. These items are not intended for high containment or deep curing, and items are typically cured 0.25 inches every 7 days from the exposed surface, depending on the humidity in the air. The operating time from product use to surface dry formation typically takes a few minutes to 1 hour, and slight warming may speed up curing, but it is recommended not to exceed 60°C (140°F).

two components condensed and cured at room temperature

Corning's two-component room temperature curing adhesives are mixed and cured quickly at room temperature to achieve good strength within 1 hour, but full performance is not achieved until a few days later. These adhesives contain their own humidity and cure evenly throughout the item, allowing for deep curing or containment, but there are some limitations.

heat curing

Corning additive curing adhesives should cure at temperatures of 100°C (212°F) or above, and cure quickly after warming。 For thicker sections or when bubbles are found, choose an adhesive with a newer one with fewer bubbles, or pre-cure at 70°C (158°F) for 30 minutes, which reduces bubbles in the elastomer. Additive curing contains all components of curing action, the curing process produces no by-products, can be cured deep or under closed coverage, the curing process is uniformly spread throughout the item, and these adhesives usually have a long working time.


Product Details


单组分室温湿气固化

类别:

无腐蚀性,单或两组分室温湿气固化硅酮弹性体;在室温条件下固化而不需加热

外观

不流动和可流动两种选择;固化成柔性弹性体

特性

室温固化;不透明和半透明两种选择;可以抵御潮湿和其它恶劣的环境;良好的介电特性;对多种普通基材具有良好的粘合性;低应力,精炼型,可快速表干;两组分物品同样可以在室温条件下提供快速固化和初期强度,以及可以深层固化。

用途

密封模块和外壳;垫圈;密封电子仪器设备及模块;固定电源供应器电路板零部件,安装CRT, LCD/LED/PDP模快、外壳、垫圈、连接电子零部件。


两组份室温缩合固化

类别

两组分室温固化硅酮弹性体

外观

不流动;固化成柔性弹性体

特性

在室温下快速固化及取得初期强度;深层固化;可以抵御潮湿和其它恶劣的环境;良好的介电特性;自粘;低应力

用途

盖子和外壳密封;垫圈


加热固化

类别

提供多种应用和固化形式的单或两组分硅酮弹性体

外观

不流动和可流动两种选择;固化成柔性弹性体;有多种固化形式和特性

特性

较低温快速热固化;可以抵御潮湿和其它恶劣的环境;良好的介电特性;自粘;低应力,固化过程中较少出现气泡

用途

盖子和外壳密封;发动机控制模块密封、电源模块; 固定电路板的电子零部件;加固或固定连接器部件;密封电子部件/模块;密封电容器和电子组件;固定回扫变压器

Product information
td class="et2" x:str="" align="left" valign="middle"> sealed electronic instruments and modules; Fixed circuit board partstd class="et2" x:str="" align="left" valign="middle"> sealed electronic instruments and modules; fixed circuit board parts
Corning products> description> features> potential or typical use
One-component room temperature humidity curing
EA-3000 white one-component, white, fast stem fast stem; low viscosity; non-corrosive (alcohol curing at room temperature); Excellent adhesion to most materials; self-adhesive; Excellent dielectric properties; Excellent thermal stability and cold resistance; RefinedLCD & EL module assembly
SE 9120 Transparent one-component, flowable; Translucent, room temperature moisture curing Fast surface drying time; non-corrosive; RefinedEL, LCD module assembly; Mixing IC and PCB coatings, sealing electronic components
SE 9120 S white one-component, flowable; white, room temperature moisture curing fast surface drying time; non-corrosive; Refined typeEL, LCD module assembly
SE 9152 HT one-component, flowable; Reddish-brown, room temperature moisture curing fast surface drying time; non-corrosive; Heat-resistant temperature up to 275°C sealed sheathed heating tube tail end
SE 9186 Transparent or white one-component, flowable; Translucent or white, room temperature moisture curing fast surface drying time; non-corrosive; Refined <
SE 9186 L Black or transparent one-component, flowable; Black or translucent, room temperature moisture curing Fast surface drying time; non-corrosive; Refined type Circuit board parts repair; LCD module assembly
SE 9187 L Black or clear or white One component, low viscosity, black, translucent or white, room temperature moisture curing fast table drying time; non-corrosive; Refined, UL 94HB (black only)LCD module assembly; LED module assembly; potting
3140 room temperature curable coatings one-component, medium flow; Translucent, room temperature moisture curing non-corrosive; Good curing strength; Contains ultraviolet fluorescence markers for automatic detection; UL 94V-1 and MIL-A-46146 seals in notches or other fluid-supporting object configurations, or where limited flow is required
SE 9189 L Grey or White Cured at room temperature one-component, medium flowability; Grey or white, room temperature moisture curing fast surface drying time; non-corrosive; Refined type; UL V-0 PDP module assembly; Fixed circuit board parts
3-1944 Room temperature curing coatings one-component, medium flow; Translucent, room temperature moisture curing Fast surface drying time; non-corrosive; Contains ultraviolet fluorescence markers; UL 94V-0 and MIL-A-46058 seals in notches or other configurations that support flow, or where limited flow is required
SE 738 white one-component, non-flowing; white, room temperature moisture curing non-corrosive; General Purpose; UL 94HB fixed circuit board capacitor coil
739 Plastic Adhesive-White non-corrosive; General Purpose; Good adhesion; UL 94V-0 Contract Fixation or CRT; Fixed power supply mold fast parts
744 room temperature curing sealant non-corrosive; Fast surface drying time; General Purpose; Good adhesion fixing large components such as batteries or circuit board capacitors
838 Silicone Adhesives/Sealants non-corrosive; General Purpose; UL 94HB openings and housings of sealing modules; Increase mechanical stability for each component; Installing components on PWBs; sealing the inner and outer edges of cables and electronic conductors; Yoke installation
839 silicone adhesives/sealants one-component, non-flowing; Translucent blue, room temperature moisture curing non-corrosive; General use openings and housings of sealing modules; Increase mechanical stability for each component; Installing components on PWBs; sealing the inner and outer edges of cables and electronic conductors; Yoke installation
3145 Room temperature curing
MIL-A-46146 Adhesives/sealants - clear
One component, Not mobile; Translucent, room temperature moisture curing non-corrosive; high tensile strength, elongation and peel shear values; Contains ultraviolet fluorescence markers for automatic detection; MIL-A-46146 Openings and housings of sealed modules; Increase mechanical stability for each component; Installing components on PWBs; sealing the inner and outer edges of cables and electronic conductors; Yoke installation
3145 Room temperature curing
MIL-A-46146 Adhesives/sealants-gray
one-component, Not mobile; Grey, room temperature moisture curing non-corrosive; high tensile strength, elongation and peel shear values; for high-temperature applications; MIL-A-46146
3165 Fast surface dry room
temperature curing adhesive/sealant 1
one-component, non-flowing; gray, room temperature moisture curing fast surface drying time; non-corrosive; Good initial strength; Good room temperature adhesion to most substrates; UL 94V-0
SE 9168 Cured at room temperature one-component, non-flowing; gray, room temperature moisture curing fast surface drying time; non-corrosive; Refined type; UL 94V-0 parts of the circuit board that fixes the CRT and power supply modules
SE 9184 White room temperature curing one-component, non-flowing; white, room temperature moisture curing fast surface drying time; non-corrosive; Refined type; Thermal conductivity; UL94V-0 Parts of the circuit board that fix the power supply module; Heat conduction of electronic components
SE 9185 Transparent or white one-component, non-flowing; Translucent or white, room temperature moisture curing fast surface drying time; non-corrosive; Refined <
SE 9188 Room temperature curing one-component, non-flowing; gray, room temperature moisture curing fast surface drying time; non-corrosive; Refined type; UL 94V-0 Parts that fix CRT, power supply module circuit board
SE 9189 White cured at room temperature one-component, non-flowing; white, room temperature moisture curing fast surface drying time; non-corrosive; Refined type; UL 94V-0; Good thermal conductivity parts of fixed power supply module circuit board
two components condensed and cured at room temperature
CY 51-019 Two components, 10:1 mixing ratio, white, condensation curing at room temperature non-corrosive; Good liquidity; Good adhesion solar cell seal
Q3-6093 room temperature curing adhesive Two components, 10:1 mixing ratio, black, room temperature condensation curing non-corrosive; self-adhesive; Fast room temperature curing and deep curing; Good initial strength; Good room temperature adhesion to most substrates seal lids and case cases; connecting substrates; washer
heat curing
Sylgard® 577 Primless Silicone Adhesive Two components, 10:1 mixing ratio, flowable, gray, Heat curing non-corrosive; Fast heating and curing; self-adhesive; High strength; UL 94V-0; MIL-PRF-23586F sealing lids and enclosures; connecting substrates; Gaskets, contact seals
866 Primless silicone adhesive one-component, flowable, gray, heat curable non-corrosive; self-adhesive; High Strength sealing lids and housings; connecting substrates; Gaskets, contact seals
SE 1701 LTV1 Two components, 10:1 mixing ratio, flowable, beige, heat cured non-corrosive; self-adhesive; High Strength sealed ceramic capacitors; sealing electronic components; Fixative for computer keyboards
SE 17131 one-component, flowable, beige, heat cured non-corrosive; self-adhesive; High strength; Good adhesion sealing ECUs cover and housing, power module; fixed circuit board electronic components; Reinforced or fixed connector assembly
SE 1714 or SE 1714 black one-component, flowable, beige or black, heat cured
SE 1720 CV1 Two components, 1:1 mixing ratio, white, low bubble rate, fast curing, refined type non-corrosive; self-adhesive; High strength; non-collapsing
SE 1750 white1 one-component, flowable, white, heat curable non-corrosive; self-adhesive; Good strength; Good adhesion sealing ECUs cover and housing, power module; fixed circuit board electronic components; Reinforced or fixed connector assembly
3-1595 Silicone Adhesives one-component, thixotropic, gray, heat cured self-adhesive; Soft seal lid and housing; Connecting the base plate; Washers; Connector sealing; engine control; ABS; Transmission Motor; lighting equipment
3-1598 HP one-component, low bubble rate, black, flowable High performance product 3-1598, which can be used especially to reduce air bubbles in cured materials
3-6265 HP one-component, low bubble rate, black, non-flowing High performance product 3-6265, which can be used especially to reduce air bubbles in cured materials
3-6876 Black adhesive One component, good flowability, black, heat cured non-corrosive; self-adhesive; Fast heating and curing; High strength; Low viscosity product Q3-6611 adhesive
3-6876 Grey Adhesive One-component, good flowability, gray, heat cured
96-083 silicone adhesive Two components, 10:1 mixing ratio, low viscosity, heat curing non-corrosive; self-adhesive; heating curing; High strength; Low viscosity fixed components; Fixing various substrates such as ceramics, plastics, glass and metals
EA-6052 Fast Low Temperature Curing Adhesive Two components, 1:1 mixing ratio, medium flow, black, Heat curing non-corrosive; Fast low-temperature curing; flowing to fill grooves; Sealed lid and housing with auto-detection UV fluorescence markers; connecting substrates; Gaskets, connector seals
X3-1598 adhesive One-component black heat curing, medium flow, high strength, Similar products Q3-6611 adhesive contains UV markers, self-adhesive non-corrosive; self-adhesive; Fast heating and curing; High strength; flowable; Contains UV fluorescence markers with automatic detection sealing lid and housing; Connecting the base plate; Washers; Connector sealing; engine control; ABS; Transmission Motor; lighting equipment
Q3-6611 Adhesive, black one-component, medium flow, black, heat cured non-corrosive; self-adhesive; Fast heating and curing; High Strength
Q3-6611 Adhesive, grey one-component, medium flow, gray, heat cured
Q5-8401 Adhesive Two components, 1:1 mixing ratio, medium flow, gray, heat curing non-corrosive; self-adhesive; High strength;
EA-6054 Thixotropic Fast Low Temperature Curing Adhesive Two components, 1:1 mixing ratio, non-flowing, black, Heat curing non-corrosive; Fast low-temperature curing; does not collapse; Sealed lid and housing with auto-detection UV fluorescence markers; Connecting the base plate; Washers; Multiplane point
SE 1700 Transparent 1 Two components, 10:1 mixing ratio, non-flowing, translucent, heat cured non-corrosive; self-adhesive; High Strength sealed ceramic capacitors; sealing electronic components; Fixative for computer keyboards
SE 1700 white 1 Two components, 10:1 mixing ratio, non-flowing, white, heat curing non-corrosive; self-adhesive; High Strength sealed ceramic capacitors; sealing electronic components; Fixative for computer keyboards
Q1-9225 Silicone Adhesive Two components, 10:1 mixing ratio, non-collapsing, white, heat cured self-adhesive; High Strength sealed ceramic capacitors; sealing electronic components; Computer keyboard fixative
3-6265 Thixotropic Adhesives one-component, non-flowing, black, heat cured non-corrosive; self-adhesive; Fast heating and curing; High strength; Non-flowing product Q3-6611 adhesive; Sealed lid and housing with auto-detection UV fluorescence markers; Connecting the base plate; Washers;Terminator seal
